HYDROGRAVEL PRO BLACK
Professional application
A geogrid dedicated to the most demanding applications in industrial construction, road infrastructure, and areas with extreme traffic intensity.
86%
Biologically active surface
850 t/m2
Load Capacity
- Height 63 mm
- Dimension 100cm/50cm
- Weight 11.2 kg
Technical parameters
Height
63 mm
Dimension
100cm/50cm
Color
Black
Weight
11.2 kg
Outer wall thickness
15.5 mm
Inner wall thickness
12 mm
Number of geogrid clusters
50
Cluster dimensions
82 mm/82 mm
Number of pieces per m2
2
Weight per 1m2
22.4 kg
Material
PP/PE
Raw Material
FULL Recycling
Dimensional stability
± 3%
Compressive strength, minimum
850 t/m2
Permissible axle load, minimum
>450kN/axle
Biologically active surface
85%
Runoff coefficient
0,11-0,20
Application for fire access roads
YES
Product intended for
General Information
The HYDROGRAVEL PRO geogrid is constructed from very thick and reinforced walls, which create a rigid load-bearing structure with high stability.
Individual geogrid clusters can be filled with mineral aggregate or a layer of fertile soil intended for grass seeding, allowing for a stable and biologically active surface.
Modules measuring 100 cm x 50 cm allow for quick and efficient installation with a limited number of connections, which directly translates into better stabilization of the entire subgrade.
The panels are joined using a specially designed interlocking system, creating a uniform surface resistant to pressure and mechanical deformation under intensive use.
Thanks to its construction, the product is widely used in industrial construction, road infrastructure, and logistics areas with high traffic intensity.
This solution is effective for constructing parking lots for heavy transport, transshipment areas, and driveways exposed to extreme loads.
Such a surface construction completely eliminates the problem of unstable ground, while maintaining natural water retention and an aesthetic appearance of the area.
Product Packaging
- Pallet size 100cm/100cm
- Pallet height 2.1m
- Pallet weight 760 kg
- Number of pieces per pallet 66
- Number of m2 per pallet 33
- Special packaging Possibility of special packaging up to a maximum pallet height of 2.6m
Documents and Certificates
Technical Data Sheet
Download
National Declaration of Performance
Download
EPD Certificate
Download
REACH Declaration
Installation Instructions for stone infill
Installation Instructions for grass seeding
